Rolled Steel Standard Efficiency 0.5 HP 6P W56C 3Ph 208-230/460//190-220/380-415 V 60 Hz IC411 - TEFC - Footless

Name: .50HP 1200 2X4 TEFC W56C 3PH NO FEET W01
Brand: WEG
SKU: FC.50406SW01
Price: 1.00 CAD
Availability: InStock

Part Number: FC.50406SW01

List Price: Please contact us for pricing

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	208-230/460//190-220/380-415 V
RPM	1200 rpm

HP	0.5 HP
Enclosure	IC411 - TEFC

Flange	C
Output	0.5 HP (0.37 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.0558 sq.ft.lb
Breakdown Torque	240 %
No Load Current	1.34-1.55/0.775 A
L. R. Amperes	9.68-8.71/4.36 A
Slip	5.83 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Not Balanced
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6203 ZZ
NDE Bearing Seal	Without Bearing Seal
