Explosion-proof Motor Standard Efficiency 0.5 HP 4P B56EX 3Ph 208-230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: .50HP 1800 2X4 EXP B56
Brand: WEG
SKU: XF.50404
Price: 775.00 CAD
Availability: InStock

Part Number: XF.50404

List Price: $775.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	0.5 HP
RPM	1800 rpm

Voltage	208-230/460 V
Enclosure	IC411 - TEFC

Frame	B56EX
Voltage	208-230/460 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	B
Locked Rotor Time	27s (cold) 15s (hot)
Rated Torque	1.50 ft.lb
LRC	6.8x(Code K)
Rated Current	1.80-1.63/0.812 A
Rated Speed	1755 rpm
Degree of Protection	IP44
Standard	NEMA MG-1
Impregnation Method	Dip and Bake Polyester
Painting	RAL 7022 207N (ISO 12944 - C2)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6203 ZZ
NDE Bearing Seal	Without Bearing Seal
