Explosion-proof Motor 0.5 HP 4P B56CEX 1Ph 115/208-230 V 60 Hz IC411 - TEFC - Foot-mounted

Name: .50HP 1800 1X2 EXP B56C
Brand: WEG
SKU: XC.50104
Price: 869.00 CAD
Availability: InStock

Part Number: XC.50104

List Price: $869.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	0.5 HP
RPM	1800 rpm

Voltage	115/208-230 V
Enclosure	IC411 - TEFC

Flange	FC 149
Output	0.5 HP (0.37 kW)
Terminal Box	Without Terminal Box
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.0978 sq.ft.lb
Breakdown Torque	220 %
No Load Current	6.00/2.59-3.00 A
L. R. Amperes	44.4/21.6-22.2 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Sealing	Without Bearing Seal
