W22 7.5 HP 4P 213/5TZ 1Ph 208-230 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 1800 230 TEFC 213/5TZ W22 1PH
Brand: WEG
SKU: TS007104W22
Price: 3474.00 CAD
Availability: InStock

Part Number: TS007104W22

List Price: $3,474.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230 V
RPM	1800 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	7.5 HP (5.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	1.09 sq.ft.lb
Breakdown Torque	260 %
No Load Current	11.0-12.8 A
L. R. Amperes	254-244 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 ZZ
NDE Bearing Seal	V'Ring
