Rolled Steel Standard Efficiency 0.75 HP 2P 56 3Ph 208-230/460//190-220/380-415 V 60 Hz IC411 - TEFC - Foot-mounted

Name: ** DO NOT USE ** USE TF.75402W01DOE
Brand: WEG
SKU: TF.75402W01
Price: 632.00 CAD
Availability: InStock

Part Number: TF.75402W01

List Price: $632.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460//190-220/380-415 V
RPM	3600 rpm

HP	0.75 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	0.75 HP (0.550 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.0517 sq.ft.lb
Breakdown Torque	290 %
No Load Current	0.948-1.10/0.550 A
L. R. Amperes	17.5-15.8/7.91 A
Slip	3.47 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Only primer
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6203 ZZ
NDE Bearing Seal	Without Bearing Seal
