W22 12.5 HP 2P 213/5TC 1Ph 208-230 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 12.5HP 3600 208-230 213/5TC TEFC W22
Brand: WEG
SKU: TC012102W22
Price: 5080.00 CAD
Availability: InStock

Part Number: TC012102W22

List Price: $5,080.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230 V
RPM	3600 rpm

HP	12.5 HP
Enclosure	IC411 - TEFC

Flange	C
Output	12.5 HP (9.2 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.6763 sq.ft.lb
Breakdown Torque	280 %
No Load Current	4.91-5.70 A
L. R. Amperes	378-337 A
Slip	2.50 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 ZZ
NDE Bearing Seal	V'Ring
