Voltage
208-230/460 V
RPM
1800 rpm
HP
7.5 HP
Enclosure
IC411 - TEFC
Frame
213/5TC
Voltage
208-230/460 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Locked Rotor Time
10s (cold) 6s (hot)
Rated Torque
22.5 ft.lb
LRC
7.7x(Code H)
Rated Current
32.0-30.0/15.0 A
Rated Speed
1750 rpm
Degree of Protection
IP55
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 7022 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6206 ZZ
Locked Rotor Torque
320 %
Noise Level
63.0 dB(A)
NDE Bearing Seal
V'Ring
Flange
C
Output
7.5 HP (5.5 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15 (1.00 @ 208V)
Moment of Inertia (J)
1.09 sq.ft.lb
Breakdown Torque
250 %
No Load Current
8.97-10.4/5.20 A
L. R. Amperes
246-231/116 A
Slip
2.78 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6308 ZZ
