Rated operational current
200 A
Enclosure
IP00
Power supply
220-575 V
Frame
3
Starting duty cycle
AC-53b 3-30:1170
Standard (3 leads)
Yes
SoftPLC (ladder programming)
No
Voltage ramp and current limit
No
Current limitation ramp
Programammable via optional
Torque control
No
Product certification
UL, CE, CS, IRAM and C-TICK
Parameterization via keypad
Available with optional
Modbus-RTU RS-232
Available with optional
Modbus-RTU USB
No
Starting regime (with ventilation kit)
AC-53b 3-30:330
Inside delta (6 leads)
No
Voltage ramp
Yes
Current limit
Yes
Pump control
Programmable via optional
Direct on line start
Programmable via optional
Parameterization via trimpots and dip switches
Yes
Parameterization via software
Superdrive G2
Modbus-RTU RS-485
Available with optional
