W22 P Base NEMA Premium Efficiency 50 HP 6P 364/5HP 3Ph 575 V 60 Hz IC411 - TEFC - Footless

Name: 50 HP 1200 575 PBASE 365HP NP W22
Brand: WEG
SKU: PB050506NPW22
Price: 30040.00 CAD
Availability: InStock

Part Number: PB050506NPW22

List Price: $30,040.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	1200 rpm

HP	50 HP
Enclosure	IC411 - TEFC

Flange	P
Output	50 HP (37 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	32s (cold) 18s (hot)
Rated Torque	222 ft.lb
LRC	6.4x(Code G)
Rated Current	45.9 A
Rated Speed	1183 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6316 C3
NDE Bearing Seal	Lip Seal
