HP
1.5 HP
RPM
3600 rpm
Voltage
115/208-230 V
Enclosure
IC01 - ODP
Frame
56C
Voltage
115/208-230 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.0629 sq.ft.lb
Breakdown Torque
270 %
No Load Current
3.20/1.38-1.60 A
L. R. Amperes
102/53.1-51.2 A
Slip
2.78 %
Mounting
F-1
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material
Without Fan Cover
Fan Material
Without fan
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6204 ZZ
NDE Bearing Seal
Without Bearing Seal
Flange
C
Output
1.5 HP (1.1 kW)
Terminal Box
Without Terminal Box
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15 (1.00 @ 208V)
Design
L
Locked Rotor Time
18s (cold) 10s (hot)
Rated Torque
2.25 ft.lb
LRC
7.7x(Code J)
Rated Current
13.3/6.90-6.65 A
Rated Speed
3500 rpm
Frequency
60 Hz
Frame Material
Rolled Steel
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6202 ZZ
Locked Rotor Torque
260 %
Noise Level
58.0 dB(A)
Sealing
Without Bearing Seal
