W22 Tru-Metric IE3 30 HP 4P 180L 3Ph 575 V 60 Hz IC411 - TEFC - B35L(E)

Name: 30 HP 1800 575 TEFC 180L AFLG NP W22 TM
Brand: WEG
SKU: MA030504W22180L
Price: 3710.00 CAD
Availability: InStock

Part Number: MA030504W22180L

List Price: $3,710.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	30 HP
RPM	1800 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	FF
Output	30 HP (22 kW)
Terminal Box	Right position
Ambient Temperature	-20°C to +40°C
Duty Cycle	S1
Service Factor	1.25
Design	N
Locked Rotor Time	32s (cold) 18s (hot)
Rated Torque	88.6 ft.lb
L. R. Amperes	274 A
Slip	1.22 %
Mounting	B35L(E)
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	2xM40x1,5
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 C3
NDE Bearing Seal	V'Ring
