W22 Tru-Metric IE3 15 HP 6P 160L 3Ph 575 V 60 Hz IC411 - TEFC - B35L(E)

Name: 15 HP 1200 575 TEFC 160L NP A FLG W22 TM
Brand: WEG
SKU: MA015506W22160L
Price: 3176.00 CAD
Availability: InStock

Part Number: MA015506W22160L

List Price: $3,176.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	15 HP
RPM	1200 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	FF
Output	15 HP (11 kW)
Terminal Box	Right position
Ambient Temperature	-20°C to +40°C
Duty Cycle	S1
Service Factor	1.25
Design	N
Locked Rotor Time	37s (cold) 21s (hot)
Rated Torque	66.8 ft.lb
L. R. Amperes	125 A
Slip	1.67 %
Mounting	B35L(E)
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	2xM40x1,5
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	V'Ring
