Multimounting High Efficiency 0.25 HP 2P 63 3Ph 208-230/460//380-415 V 60 Hz IC411 - TEFC - B35L(E)

Name: .25HP 3600 2X4 MULTI 63 B5 IE2 TM ALUM
Brand: WEG
SKU: MA.2540263A
Price: 1.00 CAD
Availability: InStock

Part Number: MA.2540263A

List Price: Please contact us for pricing

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	0.25 HP
RPM	3600 rpm

Voltage	208-230/460//380-415 V
Enclosure	IC411 - TEFC

Flange	FF
Output	0.25 HP (0.18 kW)
Terminal Box	Right position
Ambient Temperature	-20°C to +40°C
Duty Cycle	S1
Service Factor	1.15
Design	N
Locked Rotor Time	36s (cold) 20s (hot)
Rated Torque	0.386 ft.lb
L. R. Amperes	5.04/2.52 A
Slip	5.56 %
Mounting	B35L(E)
Frequency	60 Hz
Frame Material	Aluminum
Main Terminal Box Hole	NPT 1/2"
Drain	Rubber, automatic
Painting	RAL 7022 207N (ISO 12944 - C2)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	Not Balanced
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6201 ZZ
NDE Bearing Seal	Oil Seal
