W21 In Line Extra Thrust NEMA Premium Efficiency 50 HP 2P 326LP 3Ph 208-230/460 V 60 Hz IC411 - TEFC - Footless

Name: 50 HP 3600 2X4 TEFC 326LP NP
Brand: WEG
SKU: LP050402NP
Price: 19908.00 CAD
Availability: InStock

Part Number: LP050402NP

List Price: $19,908.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460 V
RPM	3600 rpm

HP	50 HP
Enclosure	IC411 - TEFC

Frame	326LP
Voltage	208-230/460 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	5.42 sq.ft.lb
Breakdown Torque	260 %
No Load Current	24.7-28.2/14.1 A
L. R. Amperes	893-806/404 A
Slip	1.11 %
Mounting	W-6
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 2"
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Aluminum
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6212 C3
NDE Bearing Seal	Lip Seal
