ELECTRIC MOTOR SINGLE PHASE ROTOR SQUIRREL CAGE 2 HP 02 56C 115/208-230 WCF2 60Hz F-1/B14R(D) IP55 JET PUMP MONO

Name: 2 HP 3600 1X2 TEFC 56C 1PH KEYED W01
Brand: WEG
SKU: KT002102W01
Price: 1070.00 CAD
Availability: InStock

Part Number: KT002102W01

List Price: $1,070.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	115/208-230V
Enclosure	IC411 - TEFC

Frame	56
Voltage	115/208-230 V
Number of Poles	2
Class	MOTOR ROLLED STEEL
Detail	NONE
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.0707 sq.ft.lb
Breakdown Torque	250 %
No Load Current	5.00/2.16-2.50 A
L. R. Amperes	136/75.0-68.1 A
Slip	2.92 %
Mounting	F-1/B14R(D)
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	Without Bearing Seal
