ELECTRIC MOTOR THREE PHASE ROTOR SQUIRREL CAGE 1 HP 04 56J 575 C/W 3 leads WCF2 60Hz F-1/B14R(D) IP55 PREMIUM EFFICIENCY JET PUMP TRIF

Name: 1 HP 1800 575 TEFC 56J 3PH THRD W01 DOE
Brand: WEG
SKU: JT000504W01DOE
Price: 1012.00 CAD
Availability: InStock

Part Number: JT000504W01DOE

List Price: $1,012.00

Quantity:

Request Different Configuration

In stock

Output	1 HP (0.75 kW)
Class	MOTOR ROLLED STEEL
Detail	IE2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.1232 sq.ft.lb
Breakdown Torque	300 %
No Load Current	0.712 A
L. R. Amperes	10.1 A
Slip	1.94 %
Mounting	F-1/B14R(D)
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Without Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
