Rolled Steel Jet Pump - J type Premium Efficiency 0.5 HP 2P W56J 3Ph 575 V 60 Hz IC411 - TEFC - Footless

Name: .50HP 3600 575 TEFC W56J JET W01 DOE
Brand: WEG
SKU: JT.50502W01DOE
Price: 321.00 CAD
Availability: InStock

Part Number: JT.50502W01DOE

List Price: $321.00

Quantity:

Request Different Configuration

Inventory: In stock

HP	0.5 HP
RPM	3600 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	C
Output	0.5 HP (0.37 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Moment of Inertia (J)	0.0190 sq.ft.lb
Breakdown Torque	360 %
No Load Current	0.334 A
L. R. Amperes	4.83 A
Slip	4.58 %
Mounting	W-6
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Not Balanced
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	V'Ring
