Rolled Steel Jet Pump - J type Standard Efficiency 0.5 HP 2P 56J 3Ph 208-230/460//190-220/380-415 V 60 Hz IC411 - TEFC - Footless

Name: .50HP 3600 2X4 TEFC W56J THRD JET W01
Brand: WEG
SKU: JT.50402W01
Price: 598.00 CAD
Availability: InStock

Part Number: JT.50402W01

List Price: $598.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460//190-220/380-415 V
RPM	3600 rpm

HP	0.5 HP
Enclosure	IC411 - TEFC

Flange	C
Output	0.5 HP (0.37 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.0453 sq.ft.lb
Breakdown Torque	300 %
No Load Current	0.776-0.900/0.450 A
L. R. Amperes	13.0-11.8/5.90 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Without Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	Without Bearing Seal
