Wjet Pump Start Capacitor 2 HP 2P E56J 1Ph 115/208-230 V 60 Hz IC01 - ODP - Footless

Name: 2 HP 3600 1X2 ODP E56J THRD JET
Brand: WEG
SKU: JO002102
Price: 532.00 CAD
Availability: InStock

Part Number: JO002102

List Price: $532.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	2 HP
RPM	3600 rpm

Voltage	115/208-230 V
Enclosure	IC01 - ODP

Flange	FC 149
Output	2 HP (1.5 kW)
Terminal Box	Without Terminal Box
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.20 (1.00 @ 208V)
Moment of Inertia (J)	0.4390 sq.ft.lb
Breakdown Torque	220 %
No Load Current	15.0/6.47-7.50 A
L. R. Amperes	136/68.4-67.9 A
Slip	4.17 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Shaft Material	AISI 304 Stainless Steel
Grounding Lugs	Without grounding point in terminal box
Fan Material	Nylon
Balancing Method	Without Key
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	CCW
Sealing	Slinger
