W22 JM Pump 10 HP 2P 213/5JM 1Ph 208-230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 10 HP 3600 2X4V 213/5JM TEFC 1PH W22
Brand: WEG
SKU: JM010102W22
Price: 2525.00 CAD
Availability: InStock

Part Number: JM010102W22

List Price: $2,525.00

Quantity:

Request Different Configuration

Inventory: In stock

HP	10 HP
RPM	3600 rpm

Voltage	208-230/460 V
Enclosure	IC411 - TEFC

Flange	C
Output	10 HP (7.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.5285 sq.ft.lb
Breakdown Torque	290 %
No Load Current	5.95-6.90/3.45 A
L. R. Amperes	293-272/136 A
Slip	2.36 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 ZZ C3
NDE Bearing Seal	V'Ring
