W22 JM Pump 1 HP 6P 182/4JM 1Ph 208-230 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 1HP 1200 230V TEFC 182/4JM 1PH W22
Brand: WEG
SKU: JM000106W22184JM
Price: 1.00 CAD
Availability: InStock

Part Number: JM000106W22184JM

List Price: Please contact us for pricing

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	1 HP
RPM	1200 rpm

Voltage	208-230 V
Enclosure	IC411 - TEFC

Flange	C
Output	1 HP (0.75 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Moment of Inertia (J)	0.5648 sq.ft.lb
Breakdown Torque	380 %
No Load Current	4.95-6.75 A
L. R. Amperes	57.4-63.7 A
Slip	1.25 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6307 ZZ
NDE Bearing Seal	V'Ring
