W21 Explosion-proof Motor NEMA Premium Efficiency 30 HP 4P 286T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 30 HP 1800 2X4 XP 286T NP W21X
Brand: WEG
SKU: HX030404NPW21X
Price: 7976.00 CAD
Availability: InStock

Part Number: HX030404NPW21X

List Price: $7,976.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	1800 rpm

HP	30 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	30 HP (22 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	30s (cold) 17s (hot)
Rated Torque	12.3 kgfm
LRC	6.1x(Code G)
Rated Current	70.2/35.1 A
Rated Speed	1770 rpm
Degree of Protection	IP55
Standard	NEMA MG-1
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Sinterized, Exd
Painting	RAL 5009 202P (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 C3
NDE Bearing Seal	Lip Seal
