Voltage
230/460//190-220/380-415 V
RPM
1200 rpm
HP
3 HP
Enclosure
IC411 - TEFC
Frame
213/5T
Voltage
230/460 V
Number of Poles
6
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
1.08 sq.ft.lb
Breakdown Torque
250 %
No Load Current
4.20/2.10 A
L. R. Amperes
52.8/26.4 A
Slip
1.67 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Rolled Steel
Main Terminal Box Hole
1.377"
Drain
Rubber, automatic
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material
Steel
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6208 ZZ
Flange
Without
Output
3 HP (2.2 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15
Design
B
Locked Rotor Time
82s (cold) 46s (hot)
Rated Torque
13.4 ft.lb
LRC
6.5x(Code H)
Rated Current
8.12/4.06 A
Rated Speed
1180 rpm
Degree of Protection
IP55
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Drip Cover
Without
NDE Bearing
6206 ZZ
Locked Rotor Torque
200 %
Noise Level
55.0 dB(A)
NDE Bearing Seal
Without Bearing Seal
