Rolled Steel NEMA Premium Efficiency 15 HP 2P 213/5TC 3Ph 575 V 60 Hz IC01 - ODP - Foot-mounted

Name: 15 HP 3600 575V ODP 213/5TC NP W01
Brand: WEG
SKU: CP015502NPW01
Price: 2848.00 CAD
Availability: InStock

Part Number: CP015502NPW01

List Price: $2,848.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	3600 rpm

HP	15 HP
Enclosure	IC01 - ODP

Frame	213/5TC
Voltage	575 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.5512 sq.ft.lb
Breakdown Torque	280 %
No Load Current	4.93 A
L. R. Amperes	93.6 A
Slip	1.81 %
Mounting	F-1
Standard	NEMA MG-1
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Without Fan Cover
Fan Material	Without fan
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6208 ZZ
NDE Bearing Seal	Without Bearing Seal
