General High Efficiency 5 HP 2P 182TC 3Ph 230/460 V 60 Hz IC01 - ODP - Foot-mounted

Name: 5 HP 3600 2X4 182/4TC ODP HE
Brand: WEG
SKU: CP005402P
Price: 1.00 CAD
Availability: InStock

Part Number: CP005402P

List Price: Please contact us for pricing

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	5 HP
RPM	3600 rpm

Voltage	230/460 V
Enclosure	IC01 - ODP

Flange	C
Output	5 HP (3.7 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	21s (cold) 12s (hot)
Rated Torque	7.48 ft.lb
LRC	7.1x(Code H)
Rated Current	12.5/6.24 A
Rated Speed	3510 rpm
Degree of Protection	IP21
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Without Fan Cover
Fan Material	Without fan
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6206 ZZ
NDE Bearing Seal	Without Bearing Seal
