HP
5 HP
RPM
3600 rpm
Voltage
230 V
Enclosure
IC01 - ODP
Frame
G56HC
Voltage
230 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
105 K
Insulation Class
F
Locked Rotor Time
10s (cold) 6s (hot)
Rated Torque
7.60 ft.lb
LRC
6.5x(Code G)
Rated Current
19.1 A
Rated Speed
3455 rpm
Degree of Protection
IP21
Standard
00006
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Manual
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Sealing
Without Bearing Seal
Flange
FC 149
Output
5 HP (3.7 kW)
Terminal Box
Without Terminal Box
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.00
Moment of Inertia (J)
0.0721 sq.ft.lb
Breakdown Torque
200 %
No Load Current
3.70 A
L. R. Amperes
124 A
Slip
4.03 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Rolled Steel
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6203 ZZ
Locked Rotor Torque
220 %
Bearing Type
6204 ZZ
NDE Bearing Seal
Without Bearing Seal
