W22 Brake Motor NEMA Premium Efficiency 30 HP 4P 284/6TC 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 30 HP 1800 575V TEFC 284/6TC BRKMTMR W22
Brand: WEG
SKU: BC030504NPW22
Price: 7092.00 CAD
Availability: InStock

Part Number: BC030504NPW22

List Price: $7,092.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	30 HP
RPM	1800 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	C
Output	30 HP (22 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	36s (cold) 20s (hot)
Rated Torque	89.0 ft.lb
LRC	6.1x(Code G)
Rated Current	28.1 A
Rated Speed	1770 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Aluminum
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 C3
NDE Bearing Seal	Lip Seal
