Explosion-proof Motor Standard Efficiency 0.33 HP 4P A56CEX 3Ph 208-230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: .33HP 1800 2X4 EXP A56C IP44
Brand: WEG
SKU: XC.33404
Price: 822.00 CAD
Availability: InStock

Part Number: XC.33404

List Price: $822.00

Quantity:

Request Different Configuration

Inventory: In stock

HP	0.33 HP
RPM	1800 rpm

Voltage	208-230/460 V
Enclosure	IC411 - TEFC

Flange	FC 149
Output	0.33 HP (0.25 kW)
Terminal Box	Without Terminal Box
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.0622 sq.ft.lb
Breakdown Torque	300 %
No Load Current	1.11-1.00/0.500 A
L. R. Amperes	7.48-6.76/3.38 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6203 ZZ
NDE Bearing Seal	Without Bearing Seal
