ELECTRIC MOTOR SINGLE PHASE 5 HP 04 182/4T 208-230 60Hz B3R(D) IP55 W22 WFF2

Name: 5 HP 1800 230/460V 182/4T 1PH TEFC W22
Brand: WEG
SKU: TS005104W22
Price: 3094.00 CAD
Availability: InStock

Part Number: TS005104W22

List Price: $3,094.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	208-230V
Enclosure	IC411 - TEFC

Flange	Without
Output	5 HP (3.7 kW)
Terminal Box	Left position
Application	W22
Polarity	04
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	0.4357 sq.ft.lb
Breakdown Torque	235 %
No Load Current	6.90-8.00/4.00 A
L. R. Amperes	150-139/69.5 A
Slip	3.89 %
Mounting	B3R
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6207 ZZ
NDE Bearing Seal	V'Ring
