*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
2 HP
RPM
1800 rpm
Voltage
115/208-230 V
Enclosure
IC411 - TEFC
Frame
56H
Voltage
115/208-230 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.1614 sq.ft.lb
Breakdown Torque
250 %
No Load Current
8.80/3.79-4.40 A
L. R. Amperes
141/75.0-70.6 A
Slip
3.61 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Rolled Steel
Main Terminal Box Hole
0.881"
Drain
Rubber, automatic
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material
Industrial polymer
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6204 ZZ
NDE Bearing Seal
Without Bearing Seal
Flange
Without
Output
2 HP (1.5 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15 (1.00 @ 208V)
Design
L
Locked Rotor Time
34s (cold) 19s (hot)
Rated Torque
6.05 ft.lb
LRC
7.5x(Code K)
Rated Current
18.8/10.0-9.41 A
Rated Speed
1735 rpm
Degree of Protection
IP55
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Drip Cover
Without
NDE Bearing
6202 ZZ
Locked Rotor Torque
290 %
Noise Level
54.0 dB(A)
Sealing
V'Ring
