HP
0.5 HP
RPM
3600 rpm
Voltage
115/208-230 V
Enclosure
IC411 - TEFC
Frame
W56
Voltage
115/208-230 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.0273 sq.ft.lb
Breakdown Torque
300 %
No Load Current
1.40/0.604-0.700 A
L. R. Amperes
40.6/22.4-20.3 A
Slip
2.50 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Rolled Steel
Main Terminal Box Hole
0.881"
Drain
Rubber, automatic
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material
Industrial polymer
Fan Material
Plastic
Balancing Method
Not Balanced
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6203 ZZ
NDE Bearing Seal
Without Bearing Seal
Flange
Without
Output
0.5 HP (0.37 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15 (1.00 @ 208V)
Design
N
Locked Rotor Time
19s (cold) 11s (hot)
Rated Torque
0.748 ft.lb
LRC
8.5x(Code L)
Rated Current
4.78/2.64-2.39 A
Rated Speed
3510 rpm
Degree of Protection
IP55
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Drip Cover
Without
NDE Bearing
6202 ZZ
Locked Rotor Torque
260 %
Noise Level
66.0 dB(A)
Sealing
V'Ring
