W22 7.5 HP 4P 213/5TC 1Ph 208-230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 1800 230 TEFC 215TCZ 1PH W22
Brand: WEG
SKU: TC007104W22
Price: 3754.00 CAD
Availability: InStock

Part Number: TC007104W22

List Price: $3,754.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460 V
RPM	1800 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Flange	C
Output	7.5 HP (5.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15 (1.00 @ 208V)
Moment of Inertia (J)	1.09 sq.ft.lb
Breakdown Torque	250 %
No Load Current	8.97-10.4/5.20 A
L. R. Amperes	246-231/116 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 ZZ
NDE Bearing Seal	V'Ring
