Saw Arbor Motor Standard Efficiency 7.5 HP 4P 90L/MS 3Ph 208-230/460 V 60 Hz IC411 - TEFC - B3R(D)

Name: 7.5HP 1800 2X4 SAW ARBOR RT 90L/MS S6
Brand: WEG
SKU: SR007404S6
Price: 6106.00 CAD
Availability: InStock

Part Number: SR007404S6

List Price: $6,106.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	208-230/460 V
RPM	1800 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Frame	90L/MS
Voltage	208-230/460 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.3325 sq.ft.lb
Breakdown Torque	400 %
No Load Current	11.1-10.0/5.02 A
Rated Current	22.4-20.3/10.1 A
Rated Speed	1730 rpm
Degree of Protection	IP54
Standard	00004
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Painting	RAL 7022 207A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Aluminum
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6308 ZZ
NDE Bearing Seal	Without Bearing Seal
