Reference
RW67
Mounting type
Direct
Current range
32-50 A
Number of poles
3 poles
Contactor model
CWM32/40
Mounting configuration
1D
Rated insulation voltage Ui (acc. to UL)
600 V
Rated operational frequency
25...400Hz
Maximum operating frequency
15 ops./h
Degree of protection - auxiliary terminals
IP20
Short circuit protection with fuses (gL/gG)
6gL/gG
Width
50 mm / 1.97 in
Gross weight
0,320 kg / 0.71 lb
Rated insulation voltage Ui
690 V
Rated impulse withstand voltage Uimp
6 kV
Suitable for use with DC loads
Yes
Degree of protection - main terminals
IP10
Max. Fuse (type 2 coordination)
125gL/gG
Height
73 mm / 2.87 in
Depth
106 mm / 4.17 in
