W22 P Base NEMA Premium Efficiency 7.5 HP 4P 213HP 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Footless

Name: 7.5HP 1800 2X4 PBASE 213HP NP W22
Brand: WEG
SKU: PB007404NPW22
Price: 3916.00 CAD
Availability: InStock

Part Number: PB007404NPW22

List Price: $3,916.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	1800 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Frame	213HP
Voltage	230/460 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	1.34 sq.ft.lb
Breakdown Torque	310 %
No Load Current	8.40/4.20 A
L. R. Amperes	130/65.2 A
Slip	1.94 %
Mounting	W-6
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 ZZ
NDE Bearing Seal	V'Ring
