W22 P Base NEMA Premium Efficiency 5 HP 2P 184HP 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Footless

Name: 5 HP 3600 2X4 PBASE 182/4HP NP W22
Brand: WEG
SKU: PB005402NPW22
Price: 2954.00 CAD
Availability: InStock

Part Number: PB005402NPW22

List Price: $2,954.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	3600 rpm

HP	5 HP
Enclosure	IC411 - TEFC

Flange	P
Output	5 HP (3.7 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	32s (cold) 18s (hot)
Rated Torque	7.50 ft.lb
LRC	7.6x(Code J)
Rated Current	11.8/5.90 A
Rated Speed	3500 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 ZZ
NDE Bearing Seal	V'Ring
