W22 P Base NEMA Premium Efficiency 1.5 HP 4P 145HP 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Footless

Name: 1.5HP 1800 2X4 PBASE 145HP NP W22
Brand: WEG
SKU: PB001404NPW22
Price: 983.00 CAD
Availability: InStock

Part Number: PB001404NPW22

List Price: $983.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	1.5 HP
RPM	1800 rpm

Voltage	230/460//380 V
Enclosure	IC411 - TEFC

Flange	P
Output	1.5 HP (1.1 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	25s (cold) 14s (hot)
Rated Torque	4.49 ft.lb
LRC	8.4x(Code L)
Rated Current	4.04/2.02 A
Rated Speed	1755 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6307 ZZ
NDE Bearing Seal	V'Ring
