W22 Tru-Metric IE3 40 HP 4P 200L 3Ph 208-230/460//380-415 V 60 Hz IC411 - TEFC - B3L(E)

Name: 40 HP 1800 2X4 MULTI 200L IE3 W22 TM
Brand: WEG
SKU: ME040404W22200L
Price: 9500.00 CAD
Availability: InStock

Part Number: ME040404W22200L

List Price: $9,500.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460//380-415 V
RPM	1800 rpm

HP	40 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	40 HP (30 kW)
Terminal Box	Right position
Ambient Temperature	-20°C to +40°C
Duty Cycle	S1
Service Factor	1.25
Design	N
Locked Rotor Time	23s (cold) 13s (hot)
Rated Torque	118 ft.lb
L. R. Amperes	909/454 A
Slip	0.83 %
Mounting	B3L(E)
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	2xM50x1,5
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6312 C3
NDE Bearing Seal	V'Ring
