W22 Tru-Metric IE3 15 HP 4P 160M 3Ph 208-230/460//380-415 V 60 Hz IC411 - TEFC - B3L(E)

Name: 15 HP 1800 2X4 MULTI 160M IE3 W22 TM
Brand: WEG
SKU: ME015404W22160M
Price: 1811.00 CAD
Availability: InStock

Part Number: ME015404W22160M

List Price: $1,811.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	15 HP
RPM	1800 rpm

Voltage	208-230/460//380-415 V
Enclosure	IC411 - TEFC

Flange	Without
Output	15 HP (11 kW)
Terminal Box	Right position
Ambient Temperature	-20°C to +40°C
Duty Cycle	S1
Service Factor	1.25
Design	N
Locked Rotor Time	28s (cold) 16s (hot)
Rated Torque	44.3 ft.lb
L. R. Amperes	309/155 A
Slip	1.11 %
Mounting	B3L(E)
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	2xM40x1,5
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	V'Ring
