W22 Tru-Metric IE3 40 HP 4P 200L 3Ph 208-230/460//380-415 V 60 Hz IC411 - TEFC - B35L(E)

Name: 40 HP 1800 2X4 TEFC 200LA FLG NEMA P W22
Brand: WEG
SKU: MA040404W22200L
Price: 5116.00 CAD
Availability: InStock

Part Number: MA040404W22200L

List Price: $5,116.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	40 HP
RPM	1800 rpm

Voltage	208-230/460//380-415 V
Enclosure	IC411 - TEFC

Frame	200L
Voltage	208-230/460 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	VFD
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	8.23 sq.ft.lb
Breakdown Torque	350 %
No Load Current	44.0-51.0/25.5 A
Rated Current	109-98.8/49.4 A
Rated Speed	1785 rpm
Degree of Protection	IP55
Standard	00004
Impregnation Method	Dip and Bake Polyester
Terminal Block	BMC - 6 pins
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6312 C3
NDE Bearing Seal	V'Ring
