W22 Tru-Metric IE3 20 HP 4P 160L 3Ph 575 V 60 Hz IC411 - TEFC - B35L(E)

Name: 20 HP 1800 575 TEFC 160LA FLG N.P W22 TM
Brand: WEG
SKU: MA020504W22160L
Price: 5136.00 CAD
Availability: InStock

Part Number: MA020504W22160L

List Price: $5,136.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	1800 rpm

HP	20 HP
Enclosure	IC411 - TEFC

Frame	160L
Voltage	575 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	2.88 sq.ft.lb
Breakdown Torque	330 %
No Load Current	8.80 A
Rated Current	20.0 A
Rated Speed	1778 rpm
Degree of Protection	IP55
Standard	00004
Impregnation Method	Dip and Bake Polyester
Terminal Block	BMC - 6 pins
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	V'Ring
