ELECTRIC MOTOR THREE PHASE 3 HP 02 56C 575 C/W 3 leads WCF2 60Hz W-6/V18R(D) IP55 PREMIUM EFFICIENCY JET PUMP TRIF

Name: 3 HP 3600 575 TEFC 56C KEY W01 DOE
Brand: WEG
SKU: KT003502W01DOE
Price: 1538.00 CAD
Availability: InStock

Part Number: KT003502W01DOE

List Price: $1,538.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	3 HP
RPM	3600 rpm

Voltage	575V
Enclosure	IC411 - TEFC

Flange	C
Output	3 HP (2.2 kW)
Terminal Box	Left position
Application	ROLLED STEEL
Power	3 HP
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.1663 sq.ft.lb
Breakdown Torque	380 %
No Load Current	1.28 A
L. R. Amperes	27.3 A
Slip	2.64 %
Mounting	W-6/V18R(D)
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	V'Ring
