ELECTRIC MOTOR THREE PHASE 1.5 HP 04 56J 575 C/W 3 leads WCF2 60Hz F-1/B14R(D) IP55 PREMIUM EFFICIENCY JET PUMP TRIF

Name: 1.5HP 1800 575 TEFC 56J 3PH THRD W01 DOE
Brand: WEG
SKU: JT001504W01DOE
Price: 1168.00 CAD
Availability: InStock

Part Number: JT001504W01DOE

List Price: $1,168.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	575V
Enclosure	IC411 - TEFC

Frame	56
Voltage	575 V
Number of Poles	4
Class	MOTOR ROLLED STEEL
Detail	IE2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.1101 sq.ft.lb
Breakdown Torque	300 %
No Load Current	0.867 A
L. R. Amperes	13.3 A
Slip	2.78 %
Mounting	F-1/B14R(D)
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Without Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 ZZ
NDE Bearing Seal	Without Bearing Seal
