Rolled Steel Jet Pump - J type Premium Efficiency 0.5 HP 4P W56J 3Ph 208-230/460 V 60 Hz IC411 - TEFC - Footless

Name: .50HP 1800 2X4 TEFC W56J THRD W01 DOE
Brand: WEG
SKU: JT.50404W01DOE
Price: 389.00 CAD
Availability: InStock

Part Number: JT.50404W01DOE

List Price: $389.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	0.5 HP
RPM	1800 rpm

Voltage	208-230/460 V
Enclosure	IC411 - TEFC

Flange	C
Output	0.5 HP (0.37 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Moment of Inertia (J)	0.0522 sq.ft.lb
Breakdown Torque	310 %
No Load Current	0.000-0.992/0.496 A
L. R. Amperes	11.0-9.98/4.98 A
Slip	3.89 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	0.881"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	Not Balanced
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	Without Bearing Seal
