W22 Close Coupled Pump JP NEMA Premium Efficiency 20 HP 4P 254/6JP 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 20 HP 1800 2X4 TEFC 254/6JP NP W22
Brand: WEG
SKU: JP020404NPW22
Price: 2557.00 CAD
Availability: InStock

Part Number: JP020404NPW22

List Price: $2,557.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	20 HP
RPM	1800 rpm

Voltage	230/460//380 V
Enclosure	IC411 - TEFC

Frame	254/6JP
Voltage	230/460 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	3.10 sq.ft.lb
Breakdown Torque	260 %
No Load Current	19.2/9.60 A
L. R. Amperes	333/166 A
Slip	1.67 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1 1/2"
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	V'Ring
