ELECTRIC MOTOR SINGLE PHASE 1 HP E56J 02 115/208-230 60Hz B14R(D) IP21 WCA1 THREAD WJET PUMP

Name: 1 HP 3600 1X2 ODP E56J THRD JET
Brand: WEG
SKU: JO000102
Price: 838.00 CAD
Availability: InStock

Part Number: JO000102

List Price: $838.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	115/208-230V
Power	1 HP

RPM

3600 rpm

Output	1 HP (0.75 kW)
Class	ELECTRIC MOTOR
Polarity	02
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.40 (1.00 @ 208V)
Moment of Inertia (J)	0.3037 sq.ft.lb
Breakdown Torque	260 %
No Load Current	7.90/3.41-3.95 A
L. R. Amperes	70.2/34.8-35.1 A
Slip	2.92 %
Mounting	B14R
Frequency	60 Hz
Frame Material	Rolled Steel
Shaft Material	AISI 304 Stainless Steel
Grounding Lugs	Without grounding point in terminal box
Fan Material	Nylon
Balancing Method	Without Key
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	CCW
Sealing	Slinger
