Rolled Steel Jet Pump - J type 0.75 HP 2P 56J 1Ph 115/208-230 V 60 Hz IC01 - ODP - Footless

Name: .75HP 3600 1X2 ODP 56J THRD W01 DOE
Brand: WEG
SKU: JO.75102W01DOE
Price: 305.00 CAD
Availability: InStock

Part Number: JO.75102W01DOE

List Price: $305.00

Quantity:

Request Different Configuration

Inventory: In stock

HP	0.75 HP
RPM	3600 rpm

Voltage	115/208-230 V
Enclosure	IC01 - ODP

Frame	56J
Voltage	115/208-230 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.0434 sq.ft.lb
Breakdown Torque	300 %
No Load Current	2.40/1.03-1.20 A
L. R. Amperes	58.5/32.3-29.2 A
Slip	2.50 %
Mounting	F-1
Standard	NEMA MG-1
Impregnation Method	Dip and Bake Polyester
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Without Fan Cover
Fan Material	Without fan
Balancing Method	Without Key
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	CCW
Bearing Type	6203 2RS
NDE Bearing Seal	Without Bearing Seal
