Wjet Pump Start Capacitor 0.75 HP 2P W56J 1Ph 115/208-230 V 60 Hz IC01 - ODP - Footless

Name: .75HP 3600 1X2 ODP W56J THRD JET
Brand: WEG
SKU: JO.75102
Price: 355.00 CAD
Availability: InStock

Part Number: JO.75102

List Price: $355.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	0.75 HP
RPM	3600 rpm

Voltage	115/208-230 V
Enclosure	IC01 - ODP

Flange	FC 149
Output	0.75 HP (0.55 kW)
Terminal Box	Without Terminal Box
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.50 (1.00 @ 208V)
Moment of Inertia (J)	0.2515 sq.ft.lb
Breakdown Torque	280 %
No Load Current	9.20/3.97-4.60 A
L. R. Amperes	60.4/28.1-30.2 A
Slip	3.75 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Shaft Material	AISI 304 Stainless Steel
Grounding Lugs	Single
Fan Material	Nylon
Balancing Method	Not Balanced
Overload Protector (Phenolic)	Automatic
Grease Type	Mobil Polyrex EM
Rotation	CCW
Sealing	Slinger
