Close Coupled Pump NEMA Premium Efficiency 40 HP 2P 286JM 3Ph 575 V 60 Hz IC01 - ODP - Footless

Name: 40 HP 3600 575V ODP 3 286JM NP VRT DRPCV
Brand: WEG
SKU: JM040502DPNPS
Price: 10180.00 CAD
Availability: InStock

Part Number: JM040502DPNPS

List Price: $10,180.00

Quantity:

Request Different Configuration

In stock

Output	40 HP (30 kW)
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	2.36 sq.ft.lb
Breakdown Torque	260 %
No Load Current	12.8 A
L. R. Amperes	241 A
Slip	1.39 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1 1/2"
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Fan Material	Without fan
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 Z C3
