Rolled Steel JM Pump NEMA Premium Efficiency 25 HP 2P 254/6JM 3Ph 230/460//190-220/380-415 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 25 HP 3600 2X4 TEFC 254/6JM NP W01
Brand: WEG
SKU: JM025402NPW01256JM
Price: 2452.00 CAD
Availability: InStock

Part Number: JM025402NPW01256JM

List Price: $2,452.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	25 HP
RPM	3600 rpm

Voltage	230/460//190-220/380-415 V
Enclosure	IC411 - TEFC

Flange	C
Output	25 HP (18.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Insulation Class	F
Moment of Inertia (J)	1.31 sq.ft.lb
Breakdown Torque	340 %
No Load Current	20.1/10.0 A
L. R. Amperes	473/237 A
Slip	1.94 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	1.732"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 Z C3
NDE Bearing Seal	Without Bearing Seal
